Details
Victory 10 4-Wheel Scooter Benefits & Features:
- Exclusive one-hand feather touch disassembly provides the ultimate quick transport system
- Battery charging port in tiller for easy charging
- Delta tiller with wraparound handles
- Backlit battery gauge
- Exclusive stylish, lightweight, non-scuffing, black, low-profile tires
- Long-lasting, high-intensity LED headlight offers optimal pathway illumination
- Lightweight pinchless hinge seat eight position rotation, sliders and viscoelastic foam inserts for increased comfort
- Easy-grip tiller adjustment knob
- Easy access tiller-mounted charger port
- Auto-connecting front-to-rear harness
- Comfortable riding
- Durable frames that add to the extra balance of scooter
| Top Speed: | 5.30 mph |
| Turning Radius: | 54" |
| Drive Range: | 13.00 miles |
| Weight Capacity: | 400.00 Lbs |
| Heaviest Piece: | 61 lbs. |
| Ground Clearance: | 2.00" |
| Max Incline Rating: | 6 ° |
| Disassembles: | Yes |
| Delta Tiller: | Yes |
| Seat Width: | 18" |
| Seat Depth: | 17 |
| Max Seat to Ground Height: | 22" |
| Lowest Seat to Ground Height: | 20.5" |
| Max Seat to Deck Height: | 19" |
| Multiple Seating Options: | Yes |
| Power Elevating Seat: | No |
| Height Adjustable Seat: | Yes |
| High-Back Seat: | Yes |
| Armrest Options: | Flip-Back Width Adjustable |
| Flip-Back Armrests: | Yes |
| Wheel Type: | Four Wheeled |
| Front Wheel Size | 10" |
| Rear Wheel Size | 10" |
| Air-Filled (Pneumatic) Tires | No |
| Overall Width: | 22.25" |
| Overall Length: | 47" |
| Transportable/Collapsible: | Yes |
| Foldable: | No |
| Battery Type: | U-1 |
| Batteries Included: | Yes |
| Battery Charger Type: | Off Board |
| Larger Battery Option: | Yes |
| Motor Size: | 24-Volt DC motor |
| Drive Type: | Rear-Wheel Drive |
| One-Hand Operation: | Yes |
| Braking System | Electronic, Regenerative, and Electromechanical |
| Basket Included | Yes |
| Headlight: | Yes |
| Weight Without Batteries: | 137.00 lbs |
| Battery Pack Weight: | 48.00 lbs |
| Expedited Shipping Available | No |
| Charging Port Location: | Tiller Battery Box |
| Product Weight: | 162 lbs |
| Box 1 | |
| Shipping Weight: | 150.00 lbs |
| Length: | 50.00" |
| Width: | 25.00" |
| Height: | 25.00" |
| Box 2 | |
| Shipping Weight | 50.00 lbs. |
| Length: | 30.00" |
| Width | 30.00" |
| Height: | 31.00" |
Warranty Information for the Victory 10 4-Wheel
LIFETIME LIMITED WARRANTY
For the lifetime of your product from the date of purchase, Pride will repair or replace at our option to the original purchaser, free of charge, any of the following parts found upon examination by an authorized representative of Pride to be defective in material and/or workmanship: Structural Frame Components, including:
• Main Frame - Fork - Seat Post - Tiller Frame
TWO-YEAR LIMITED WARRANTY
For two (2) years from the date of purchase, Pride will repair or replace at our option to the original purchaser, free of charge, any of the following parts found upon examination by an authorized representative of Pride to be defective in material and/or workmanship:
• Transaxle
• Brake
• Bushings
• Bearings
• Motor Brake (electronic function ONLY)
For the lifetime of your product from the date of purchase, Pride will repair or replace at our option to the original purchaser, free of charge, any of the following parts found upon examination by an authorized representative of Pride to be defective in material and/or workmanship: Structural Frame Components, including:
• Main Frame - Fork - Seat Post - Tiller Frame
TWO-YEAR LIMITED WARRANTY
For two (2) years from the date of purchase, Pride will repair or replace at our option to the original purchaser, free of charge, any of the following parts found upon examination by an authorized representative of Pride to be defective in material and/or workmanship:
• Transaxle
• Brake
• Bushings
• Bearings
• Motor Brake (electronic function ONLY)
• Electronic Controllers
• Chargers
• Harnesses
• Any Other Electrical Subassembly
NOTE: The battery is covered by a separate six-month warranty, provided by the battery manufacturer. The batteries are not warranted by Pride.
